Specifications |
|||
|---|---|---|---|
Used 2.0" Welex Extruder
- 30:1 L/D Ratio, Vented Barrel
- Air Cooled Barrel, 6 Barrel Zones
- 10:1 Koellmann Gearbox Rated To 48 HP
- 25 HP US Motors AC Motor With SECO SV3000 AC Vector Drive
- 3" x 2.5" Rectangular Feed Throat
- Center Of Vent Located Approx. 38" From Center Of Feed Throat
- 1.4:1 Belt Ratio, 125 RPM Approximate Screw Speed
- Temperature Control Panel With 6 Barrel Zones And 2 Downstream Zones, Breakers,
- Mercury Relays
- Bolt On Flange With Swing Gate
- 100 Amp Disconnect
- 460/3/60
Includes Screw, 3 Hole Strand Die, Hopper, Accu-Rate Dry Material Feeder Approximate Dimensions And Weight: 106" L x 60" W x 90" H |
|||
